Large Magnetic Particle Clutches

Operating range from 0.2 lb-ft to 300 lb-ft of torque.

Magnetic particle clutches are maintenance free and ideal for clean room operation or use in any production area where traditional dust emissions from friction surfaces are not permitted. Also called powder clutches, these units provide smooth and repeatable torque output proportional to electric input current.

DFE has partnered with Placid Industries to deliver high quality magnetic particle clutches perfect for use with our closed-loop tension controllers and load cells. In our experience, Placid Industries’ clutches deliver some of the widest torque ranges available with ultra smooth engagement. These important characteristics make Placid Industries’ clutches ideal for use in high-performance tension control systems.

For assistance sizing a magnetic particle clutches or a complete tension control system, e-mail an applications engineer today or complete the ‘Request Info’ form below.

Placid Industries’ brakes and clutches are manufactured to exacting standards in the USA and come with a one year warranty. Most models are available to ship in 1-2 days.

Do you have more questions about this product?
Complete the form below and a DFE Applications Engineer will contact you shortly.

DFE does not share information with 3rd party advertisers.

Model	Torque Range	Max RPM	Slip Heat Dissipation (watts)	Max Overhung Load (watts)	Weight (lbs)
KC-2.5	0.2-15 lb.-ft.	1800	130-260	90	21
KC-5	0.5-38 lb.-ft.	1800	190-425	125	35
PHC-50	1-30 lb.-ft.	1000	250-400	125	26
PHC-100	1-65 lb.-ft.	1000	400-800	175	46
POC-100F	0.5-70 lb.-ft.	1800	300-800	175	87
POC-200F	2-130 lb.-ft.	1800	425-1200	200	147
POC-400F	4-300 lb.-ft.	1800	550-1900	325	259
