TA500-EIP Tension Load Cell Amplifier / Signal Conditioner
An easy-to-use load cell amplifier with simultaneous EtherNet/IP™, 0-10 VDC and 4-20 mA connectivity.
The TA500-EIP Tension Amplifier is a compact, single-channel tension transducer interface with EtherNet/IP™ connectivity. It can be used with DFE tension transducers (load cells) to monitor tension in any zone of web or filament processing machinery.
DFE’s Quik-Cal™ push-button zero and calibration eliminates pot adjustments and associated drift to make calibrating the TA500 simple, fast and reliable. Powered by 24 VDC, the amplifier boosts a millivolt-level tension signal from tension transducers (load cells) and provides simultaneous EtherNet/IP™, 0-10 VDC and 4-20 mA connections to interface with a PLC, drive or display meter.
Built-in diagnostic capability quickly identifies faulty load cells, incorrect wiring, calibration issues and amplifier ADC/DAC failure.
The compact size and diverse integration capabilities of the TA500 amplifier make it a preferred option for OEMs and end users seeking next-generation monitoring and control solutions designed to support Industry 4.0.
FEATURES
• Simultaneous EtherNet/IP™, 0-10 VDC and 4-20 mA connections
• Web browser configuration interface
• EDS file support
• Powered by 24 VDC
• Quik-Cal™ push-button zero and calibration enables rapid startup
• Operating status LED
• Built-in diagnostic capability
• Remote zero and calibration
• Calibration and button lockout
• DIN rail mounting clip
• Industry-leading 5 year tension-free warranty
• Interoperable with standard or extended range (XR) transducers
• CE-marked and RoHS qualified
• ODVA conformant
BENEFITS
• Provides an easy upgrade path for analog systems migrating to Ethernet
• Improves machine operation and productivity by making it simple and economical to run proper tension
• Reliable, feature-rich device integrates easily with Allen-Bradley PLCs
• Built-in diagnostic capability reduces troubleshooting time and frustration
• Flexible signal outputs
• Secure equipment configurations via lockout commands
Do you have more questions about this product?
Complete the form below and a DFE Applications Engineer will contact you shortly.
DFE does not share information with 3rd party advertisers.
ELECTRICAL
Power Input:
Voltage: 24 VDC +/- 10%
Current: 0.15 ADC typical, internal fusing
PTC resettable
Tension Amplifier Accuracy:
+/- 1/2% drift at ambient maximum
Calibration Range: Up to 50:1
Processor: 32 bit
ADC Resolution: 24 bit (16 bit effective)
DAC Resolution: 4,096 (12 bit)
Certifications: ODVA®, EtherNet/IP™, CE
Tension Outputs:
Output 1: 0-10 VDC isolated from 24 VDC
input ground
Output 2: 4-20ma isolated from 24 VDC
input ground
Temperature Range: 32°F to 122°F (0°C to 50°C
MECHANICAL
Dimensions:
1.01 W x 3.05 H x 3.70 D (inches)
25.76 W x 77.51 H x 94.10 D (mm)
Weight: .25lbs (114g)
Enclosure: Polycarbonate with removable
terminal blocks
Included Hardware: DIN rail clip
Reference Documents
Configuration Files
Complete the form to enable your file download
| Product Code | Signal Type | Input Power | Mounting Type |
| TA500-EIP | 0-10 VDC, 4-20 mA, EtherNet/IP™ | 24 VDC | DIN Rail |
