TA1 TrueTension™ Load Cell Amplifier / Signal Conditioner
A low-cost, easy-to-use, tension load cell amplifier with simultaneous 0-10 VDC and 4-20ma signal outputs.
The TA1 TrueTension™ Amplifier is a compact, single-channel tension transducer interface. It can be used with DFE tension transducers (load cells) to monitor tension in any zone of web or filament processing machinery.
DFE’s Quik-Cal™ push-button zero and calibration eliminates pot adjustments and associated drift to make calibrating the TA1 simple, fast and reliable. Powered by 24 VDC, the amplifier boosts a millivolt-level tension signal from the tension transducer (load cell) and outputs an isolated 0-10 VDC and 4-20 mA proportional signal to a PLC, drive or display meter.
Built-in diagnostic capability quickly identifies faulty load cells, incorrect wiring, calibration issues and amplifier ADC/DAC failure. The compact size and ease-of-installation make the TA1 amplifier a natural choice for the OEM or end user seeking value in web tension monitoring or control applications.
FEATURES
• Powered by 24 VDC
• Quik-Cal™ push-button zero and calibration enables rapid startup
• Simultaneous 0-10 VDC and 4-20 mA isolated outputs
• Operating status LED
• Built-in diagnostic capability
• Remote zero and calibration
• Dual calibration function provides the ability to toggle two calibration ranges
• User configurable DIN rail or screw mounting
• Industry-leading 5 year tension-free warranty
• Interoperable with standard or extended range (XR) transducers
• CE-marked
• UL Listed to Canada and US standards
BENEFITS
• Improves machine operation and productivity by making it simple and economical to run proper tension
• Low-cost, high-quality device for reliable stand-alone tension measurement or use with advanced closed-loop control systems
• Built-in diagnostic capability reduces troubleshooting time and frustration
• Flexible signal output and mounting options
Do you have more questions about this product?
Complete the form below and a DFE Applications Engineer will contact you shortly.
DFE does not share information with 3rd party advertisers.
ELECTRICAL
Power Input:
Voltage: 24 VDC +/- 10%
Current: 0.1 ADC typical, internal fusing
PTC resettable
Tension Amplifier Accuracy:
+/- 1/2% drift at ambient maximum
Calibration Range: Up to 50:1
Processor: 32 bit
ADC Resolution: 16,777,216 (24 bit)
DAC Resolution: 4,096 (12 bit)
Certifications: CE, UL listed
Tension Outputs:
Output 1: 0-10 VDC isolated from 24 VDC
input ground
Output 2: 4-20ma isolated from 24 VDC
input ground
Temperature Range: 32°F to 122°F (0°C to 50°C
MECHANICAL
Dimensions:
.89 W x 3.9 H x 4.41 D (inches)
22.6 W x 99 H x 112 D (mm)
Weight: .25lbs (114g)
Enclosure: Polycarbonate with removable
terminal blocks
Included Hardware: DIN rail clip, screw prongs
Reference Documents
Complete the form to enable your file download
| Product Code | Signal Output | Input Power | Mounting Type |
| TA1 | 0-10 VDC, 4-20 mA | 24 VDC | Screw, DIN Rail |
